IDS peak 2.10.0 / uEye+ firmware 3.34

IDS Peak comfortSDK, genericSDK, IPL, and AFL developer manuals are external documents. Please contact us if you need them.

The settings in the "General" tab refer to the display in the IDS peak Cockpit.

Fig. 248: General settings

Fig. 248: General settings

Start image acquisition when opening a camera
If the switch is enabled, the camera starts image acquisition and display immediately after opening.

Show connecting lines between dialogs
Enable this option to show lines between related windows. This is useful if you have opened multiple cameras, as the lines show you the mapping between the camera window and the respective dialogs.

Show grid
Here, you can display a grid in the main window to align the opened camera windows and dialogs.

Language
Here, you can change the language of the program interface.

Theme
Here, you can switch between a light and a dark design for the user interface.

Default workspace
You can specify here the workspace that will be loaded when the program starts. The "No workspace" setting starts the IDS peak Cockpit without opening a camera or loading a workspace. The "last_workspace" setting is automatically saved when the program is closed, so that the last settings are restored the next time the program is started.

Workspace path
Here, you select the location for self-defined workspaces, see Creating your own workspace.
