CoaXPress Line scan camera JAI SW-2005M-CXP JAI SW-2005M-CXP
CoaXPress Camera
Proprietary Sensor
2048x1 Resolution
Line Scan Camera

get a quote for this product

The JAI Sweep SW-2005M-CXP monochrome line scan camera features a fast CoaXPress interface with a 172 kHz line rate, 2K (2048x1) resolution, and a C-mount lens mount. With their compact size and fast data transmission, Sweep cameras are suitable for a wide range of industrial applications such as inspection and scanning applications.

JAI Sweep monochrome and trilinear line scan cameras are available in a range of configurations with resolutions from 2K to 8K, and line rates up to 200 kHz.

JAI Sweep Series
Monochrome and Trilinear Line Scan Cameras Features

  • 5GigE, CoaXPress, or SFP+ interface
  • Trilinear or monochrome cameras
  • Line rates up to 200 kHz
  • Attractive pricing

SW-2005M-CXP Camera Features

  • 2K (2048x1) resolution
  • Monochrome camera
  • CoaXPress interface
  • 172 Khz line rate
SW-2005M-CXP Datasheet SW-2005M-CXP Manual All JAI Cameras
Manufacturer: JAI Model: SW-2005M-CXP Total Pixels: 2,048
Resolution: 2048 (h) 1 (v) Sensor Size: 14.3mm Color/B & W: Monochrome
kHz: 172 Sensor Type: CMOS Sensor Device: Proprietary
Pixel Size(µm): 7(h) 7(v) A/D Bits: 12 Shutter Speed: 3 µs to 15.015 µs
Interface: CoaXPress Voltage(VDC): PoCXP /18.5-26V Power(watts): call
Lens Mount: C Shutter Type: Global Weight(grams): call
S/N Ratio(dB): call External Trigger: Yes Dimensions(mm): 54Lx44Wx44H

JAI Camera Resources


click to calculate FOV/FL for this camera

Lens Calculator


Click to see our wide selection of camera accessories Camera Accessories


JAI Whitepaper Prism Technology - click to read

JAI Prism Technology
